Auxiliary Springs 2400/2500-Series

Home/Specialty Products/Auxiliary Springs 2400/2500-Series
Auxiliary Springs 2400/2500-Series

Auxiliary Springs 2400/2500-Series

SKU: AuxHdw

Description

Auxiliary Springs Type

2000 SERIES

2400 STEEL

2410 STEEL

2430 STEEL

2440 STEEL

2500 STEEL

2510 STEEL

2520 STEEL

ANSI K87444

  • WROUGHT STEEL HEADS
  • ECONOMICAL CLOSING DEVICE
  • ADJUSTABLE SPRING TENSION
  • DO NOT APPLY MORE THAN 3 HOLES TENSION
  • NON-HANDED

Product Specifications

ITEM NUMBER OVERALL LENGTH MAXIMUM DOOR WT WOOD SCREW BOX QTY CASE QTY CASE WT
2400 8 5/16" 50 lbs. 8 X 3/4 ROUND HEAD 12 ea. 72 ea. 44 lbs.
2410 9 5/16" 50 lbs. 8 X 3/4 ROUND HEAD 12 ea. 72 ea. 51 lbs.
2430 11 5/8" 50 lbs. 12 X 1 1/4 ROUND HEAD 6 ea. 24 ea. 34 lbs.
2440 12 3/4" 50 lbs. 12 X 1 1/4 ROUND HEAD 6 ea. 24 ea. 44 lbs.
2500 10 7/16" 50 lbs. 8 X 3/4 ROUND HEAD 12 ea. 72 ea. 49 lbs.
2510 13 7/16" 50 lbs. 12 X 1 1/4 ROUND HEAD 6 ea. 24 ea. 36 lbs.
2520 14 5/8" 50 lbs. 12 X 1 1/4 ROUND HEAD 6 ea. 24 ea. 45 lbs.
